Graphics

The TermGraphics class offers a variety of methods for fill a cell buffer.

  1. Create graphics type by buffer:

    final TermDim winSize = terminal.windowSize(); TermGraphics termGraphics = TermGraphics.create(winSize);

  2. Execute some graphic fill methods:

    termGraphics.foregroundColor(TerminalColor.GREEN); termGraphics.fillRect(2, 2, 5, 5, '#');

  3. Display graphics buffer to terminal screen:

    ScreenRenderer fastScreenRenderer = new FastScreenRenderer(terminal); fastScreenRenderer.render(termGraphics.buffer(), new TerminalState());

Console:

output

BoxShape

A box shape is a visual way to show frame symbols
Frame symbol types: NORMAL, BRIGHT, DOUBLE

BoxShape boxShape = new BoxShape(new TermDim(16, 16)); boxShape.addBox(1, 1, 16, 16, Type.DOUBLE); //x1, y1, x2, y2, type boxShape.addVertical(8, 1, 16, Type.NORMAL); //x1, y1, y2, type boxShape.addHorizontal(1, 8, 16, Type.NORMAL); //x1, y1, x2, type boxShape.addHorizontal(1, 4, 16, Type.BRIGHT); //x1, y1, x2, type boxShape.addVertical(12, 8, 16, Type.DOUBLE); //x1, y1, y2, type termGraphics.drawShape(1, 1, boxShape);
output

addVertical(x1,y1,y2,type)
addHorizontal(x1,y1,x2,type)
addBox(x1,y1,x2,y2,type)
